Tenpin Bowling Specifications


It doesn’t take a lot of space to make a lot of money with QubicaAMF.

Space requirements for a complete bowling center with space for snack and beverage bars, offices, pro shop, bathrooms and arcade averages 92,9m2 per lane with a depth of 45,7m. The necessary width of the bowling lanes is determined by the amount of lanes being placed. View the table below for measurements per amount of lanes.

Bowltech can provide custom technical drawings (CAD) with specs and measurements for your future center. Please contact us for more information.

# of lanes

Width in Meters

2

3,458 m

4

6,845 m

6

10,233 m

8

13,621 m

10

17,009 m

12

20,396 m

14

23,784 m

16

27,172 m

18

30,559 m

20

33,947 m

22

37,335 m

24

40,723 m

26

44,110 m

28

47,498 m

30

50,886 m


Measurements with Tenpin Bowling


XLI EDGE (Freefall Pinspotter) - Machine Only

Measurement

Metric

Width

340,4 cm

Length

279,4 cm

Height

178,38 cm

Weight

1769 kg





Power

Watts

Current Draw

Recommended Branch Circuit

Odd Pinspotter

208/220 vac

1500

7.2/6.8 amps

220 vac, 20 amp single phase

Even Pinspotter

208/220 vac

1500

7.2/6.8 amps

220 vac, 20 amp single phase

Logic Chassis

208/220 vac

400

1.9/1.8 amps

220 vac, may be tied into either pinspotter circuit





Edge String (String Pinspotter) - Machine Only

Measurement

Metric

Width

3454mm

Length

2692 mm

Height

2007 mm

Weight

1091 KG





Power

Watts

Current Draw

Recommended Branch Circuit

All

208-230 vac 50 / 60 hz

 1200W (max)

0.046Kwh

208 -230 vac, 5 amp single phase
(1 lane pair per circuit)
